Specifically designed for outdoor storage and dispensing from 55-gallon drums containing flammable or combustible liquids.  Outer wall is constructed of all-welded 16 or 12 gauge steel.  Inner wall is constructed of 18 gauge steel.  The double wall construction contains 3" of air space throughout.  All models are designed in accordance with the standards set forth by NFPA Code 30 and comply with OSHA and EPA regulations.  All models are FM Approved for the storing and dispensing of flammable and combustible liquids.

Features Include:

  • Available with 2 or 4 hour fire rating
  • Chemical/corrosive/ultraviolet resistant paint
  • Leak tight sump
  • Explosion relief panels standard
  • Removable galvanized steel grating
  • Forklift channels for easy mobility



  Model Number Test Lab Approv. Fire Rating Drum Capacities Approx. Exterior Dimensions (HxWxD)in. Approx. Shp. Wt. lbs.

B200X - Stores 2/55-gallon drums

 B200X FM*+ Standard 2 7'1" x 5' x 3'6" 1,352
B200XFR2 FM*+ 2 Hour Fire Rating 2 7'1" x 5' x 3'6" 1,730
B200XFR4 FM*+ 4 Hour Fire Rating 2 7'1" x 5' x 3'6" 2,108

B400X FM*+ Standard 4 7'1" x 5' x 5' 1,649
B400XFR2 FM*+ 2 Hour Fire Rating 4 7'1" x 5' x 5' 2,038
B400XFR4 FM*+ 4 Hour Fire Rating 4 7'1" x 5' x 5' 2,427

B600X FM*+ Standard 6 8'6" x 7' x 5' 2,051
B600XFR2 FM*+ 2 Hour Fire Rating 6 8'6" x 7' x 5' 2,528
B600XFR4 FM*+ 4 Hour Fire Rating 6 8'6" x 7' x 5' 3,005

B900X FM*+ Standard 9 8'6" x 7' x 7' 2,590
B900XFR2 FM*+ 2 Hour Fire Rating 9 8'6" x 7' x 7' 3,156
B900XFR4 FM*+ 4 Hour Fire Rating 9 8'6" x 7' x 7' 3,722

B1200X FM*+ Standard 12 8'6" x 7' x 9' 3,224
B1200XFR2 FM*+ 2 Hour Fire Rating 12 8'6" x 7' x 9' 3,878
B1200XFR4 FM*+ 4 Hour Fire Rating 12 8'6" x 7' x 9' 4,532

B1600X FM*+ Standard 16 8'6" x 10' x 8' 4,808
B1600XFR2 FM*+ 2 Hour Fire Rating 16 8'6" x 10' x 8' 5,825
B1600XFR4 FM*+ 4 Hour Fire Rating 16 8'6" x 10' x 8' 6,842

Photo Coming

Soon

 B2400X FM*+ Standard 24 8'6" x 14' x 8' 6,013
B2400XFR2 FM*+ 2 Hour Fire Rating 24 8'6" x 14' x 8' 7,340
B2400XFR4 FM*+ 4 Hour Fire Rating 24 8'6" x 14' x 8' 8,667

B3200X FM*+ Standard 32 8'6" x 18' x 8' 7,574
B3200XFR2 FM*+ 2 Hour Fire Rating 32 8'6" x 18' x 8' 9,212
B3200XFR4 FM*+ 4 Hour Fire Rating 32 8'6" x 18' x 8' 10,850



Photo Coming

Soon

 B4800X FM*+ Standard 48 8'6" x 26' x 8' 9,963
B4800XFR2 FM*+ 2 Hour Fire Rating 48 8'6" x 26' x 8' 12,222
B4800XFR4 FM*+ 4 Hour Fire Rating 48 8'6" x 26' x 8' 14,481


B6400X FM*+ Standard 64 8'6" x 34' x 8' 12,851
B6400XFR2 FM*+ 2 Hour Fire Rating 64 8'6" x 34' x 8' 15,731
B6400XFR4 FM*+ 4 Hour Fire Rating 64 8'6" x 34' x 8' 19,611

B8000X FM*+ Standard 80 8'6" x 42' x 8' 15,369
B8000XFR2 FM*+ 2 Hour Fire Rating 80 8'6" x 42' x 8' 18,870
B8000XFR4 FM*+ 4 Hour Fire Rating 80 8'6" x 42' x 8' 22,371
Please Note: Some building photos may show optional accessories.

*Complies with OSHA regulations.
FM-Factory Mutual Approved.
+All cabinets are designed in accordance with specifications set forth by the National Fire Protection Association.











SECURALL®  offers a complete line of safety storage buildings specifically designed for
storing agri-chemicals and equipment safely.  All buildings are designed to help you
comply with safety rules when mixing and handling pesticides.  These specially designed
buildings are perfect for Golf Courses, Farms, Nurseries, Greenhouses and Landscape
Contractors.  SECURALL®  buildings help reduce the risk of poisoning and injuries
among pesticide handlers and agricultural employees and will also help you protect
against chemical spills, children and animal poisonings, theft, fire and unauthorized personnel.

Features Include:

  • High security lock
  • Fiberglass insulated walls
  • Fluorescent interior lights
  • Chemical/corrosive/ultraviolet resistant paint
  • Optional leak tight steel shelves
  • Forklift channels for easy mobility





  Model Number Test Lab Approv. Description Capacities Approx. Exterior Dimensions (HxWxD)in. Approx. Shp. Wt. lbs.
Photo Coming Soon AG200 FM*+ Outdoor storage for agri-chemical material 68.4 Cubic Feet 7'1" x 5' x 3'6" 1,352

Photo Coming Soon AG400 FM*+ Outdoor storage for agri-chemical material 145.1 Cubic Feet 7'1" x 5' x 5' 1,649

AG600 FM*+ Outdoor storage for agri-chemical material 211.4 Cubic Feet 8'6" x 7' x 5' 2,051

AG900 FM*+ Outdoor storage for agri-chemical material 308.1 Cubic Feet 8'6" x 7' x 7' 2,590

AG1200 FM*+ Outdoor storage for agri-chemical material 404.7 Cubic Feet 8'6" x 7' x 9' 3,224

AG1600 FM*+ Outdoor storage for agri-chemical material 524.1 Cubic Feet 8'6" x 10' x 8' 4,751

AG2400 FM*+ Outdoor storage for agri-chemical material 747.7 Cubic Feet 8'6" x 14' x 8' 5,913

AG3200 FM*+ Outdoor storage for agri-chemical material 971.3 Cubic Feet 8'6" x 18' x 8' 7,400

AG4800 FM*+ Outdoor storage for agri-chemical material 1418.5 Cubic Feet 8'6" x 26' x 8' 9,761

Photo Coming Soon AG6400 FM*+ Outdoor storage for agri-chemical material 1865.7 Cubic Feet 8'6" x 34' x 8' 12,629

Photo Coming Soon AG8000 FM*+ Outdoor storage for agri-chemical material 2313.0 Cubic Feet 8'6" x 42' x 8' 14,201
Please Note: Some building photos may show optional accessories.
*Complies with OSHA regulations.
FM-Factory Mutual Approved.
+All cabinets are designed in accordance with specifications set forth by the National Fire Protection Association.
